| Parameter | Specification |
|---|---|
| Model | KDJS-QM |
| Input Power | AC 220V ±10V, 50Hz ±0.1Hz |
| Control Console Output | 0–250 V, max 20 A |
| Rated HV Output | 50 kV AC |
| Rated Capacity | 5 kVA |
| Voltage Measurement Accuracy | ±1% ±3 digits |
| Current Measurement Accuracy | ±1% ±3 digits |
| Timer Range | 0–99 minutes (user-settable) |
| Operating Environment | Temperature: –10°C to +40°C Humidity: ≤90% RH (non-condensing, no flashover) |
| Dimensions | - Control Box: 380 × 300 × 450 mm - Test Transformer: 300 × 300 × 500 mm - Test Stand: 100 × 760 × 1150 mm |
| Weights | - Control Box: 22 kg - Transformer: 30 kg - Test Stand: 50 kg |
