IP2C Steel Ball Test Probe with 50 N Push Force – Rigid Access Probe for IP20C Protection Rating Ver
IP2C Steel Ball Test Probe with 50 N Push Force – Rigid Access Probe for IP20C Protection Rating Ver

IP2C Steel Ball Test Probe with 50 N Push Force – Rigid Access Probe for IP20C Protection Rating Ver

Applications:

  • Verification of IP20C / IP2X protection rating (protection against solid objects ≥12.5 mm)
  • Safety testing of plugs, socket-outlets, connectors, and appliance enclosures per GB 2099.1, IEC 60884, and IEC 60335
  • Compliance checks in CCC, CE, UL, and other global safety certification processes
  • Use in national metrology institutes, third-party testing labs, and manufacturer QA departments

  • Response within
    24 hours

  • Free warranty
    12 month

  • On-line training
    Support

Profile:

Unlike the articulated IP2X finger (Test Probe B), the IP2C probe uses a rigid straight design with a smooth steel ball tip, simulating access by blunt tools or large foreign objects. The built-in 50 N push force ensures standardized mechanical stress during testing, as required by certain national and product-specific safety standards (e.g., Chinese GB standards referencing “IP20C”).

Features:

  • Rigid steel construction with polished 12.5 mm diameter spherical tip
  • Integrated 50 N ±5 N push-force mechanism (spring-loaded or force-calibrated)
  • Stop plate: 10 mm diameter × 4 mm thick, prevents over-insertion
  • Slim handle: 4 mm diameter for precise handling
  • Complies with:
    • IEC 61032 (general requirements)
    • IEC 60529 / GB/T 4208 (IP code)
    • GB 2099.1 (plugs and socket-outlets)
  • Designed for IP20C—a variant often referenced in Chinese standards where “C” denotes use of a rigid probe (vs. articulated finger)

Parameter:

Parameter Specification
Probe Ball Diameter 12.5 mm (steel, smooth surface)
Stop Plate Diameter 10 mm
Stop Plate Thickness 4 mm
Handle Diameter 4 mm
Push Force (Optional) 50 N ±5 N (calibrated)
Applicable Rating IP20C / IP2X (rigid probe method)
Reference Standards IEC 61032
IEC 60529
GB/T 4208
GB 2099.1
