KDHG-Ⅱ transformer characteristics comprehensive tester
KDHG-Ⅱ transformer characteristics comprehensive tester

KDHG-Ⅱ transformer characteristics comprehensive tester

Applications:

Only a simple digital setting is required: set the rated parameters of the transformer. The instrument will automatically record the data of the whole process, and automatically calculate and display the ratio polarity, volt-ampere characteristic curve, etc., eliminating the tedious labor of line change, manual voltage regulation, manual recording, sorting, and curve description.

  • Response within
    24 hours

  • Free warranty
    12 month

  • On-line training
    Support

Profile:

The simple operation and connection method is used to realize the measurement of the transformer, which reduces the work intensity and improves the work efficiency, and facilitates the measurement of the transformer on site. Fast, simple, accurate and convenient.

High output voltage, large capacity
Volt-ampere characteristic test: the maximum output voltage of a single machine is up to 1000V; It can be used to test the volt-ampere characteristics of 100KV 1A current transformer. Variable ratio test: Maximum current output up to 600A. The power of the whole machine is 3KVA, the power output of the equipment is all the real voltage and current value, and the waveform is the standard sine wave, the frequency is 50Hz; It can effectively simulate the real state of the transformer and meet the relevant national maintenance regulations. The minimum voltage regulation resolution can reach 0.0045V

Features:

Fully functional
CT/PT can be tested: "volt-ampere characteristics", "5%, 10% and 15% error curves", "ratio, polarity" and "secondary load", "secondary loop", "secondary withstand voltage" and demagnetization function.
The test meets GB1208, GB1207 and other transformer standards, and automatically selects which standard to test according to the type and level of the transformer.
7 inch color touch screen with Chinese input method, you can input Chinese number.
Friendly and beautiful interface, all Chinese graphical interface, panel with printer, can print curves and test data at any time.
With a large capacity memory, can store 4000 groups of test data, data power off without loss;
After the test is completed, the data is stored in the U disk, and the data can be analyzed by software on the computer side, and the WORD report can be generated.
Inflection point automatic calculation function; With perfect data query, browse, print, delete function; Comes with date/time function.
Single-machine integration, light weight, only 22Kg, easy to carry, easy to flow test.

Parameter:

Main technical parameters
Test Purposes Protection and measurement CT, protection PT

Input power:
Voltage: AC220V/±10%
Frequency: 50Hz/±10%
Maximum power: 3KVA

CT voltammetry:
Maximum voltage: 0~1000V
Maximum current: 5A effective value, 20A calculated value.
Accuracy: ±0.5%

CT ratio:
Maximum current: 0-600A
Maximum voltage: 0-5V
Accuracy: ±0.5%

PT voltamere:
Maximum voltage: safety limit 0~500V
Maximum current: 20A
Accuracy: ±0.5%

PT ratio:
Maximum voltage: 0~1000V
Accuracy: ±0.5%

Primary flow range: 0~200A/5 minutes

Secondary voltage range: 0~1000V/5 minutes

Environmental Conditions:
Operating temperature and storage temperature: -10 ° C to +50 ° C

Relative humidity: 45% ~ 60%, no condensation
Instrument size: 350mm×240mm×270mm
Weight: 22kg
