The KD2671A Digital Ground Resistance Tester is a versatile diagnostic instrument designed for a wide range of industries, including electric power, telecommunications, railways, petrochemicals, and mining. It is used to measure the grounding resistance of various electrical installations to ensure safety and compliance. In addition to ground resistance, this tester is capable of measuring the resistance of low-resistance conductors, soil resistivity, and ground voltage, making it an essential tool for installation, maintenance, and safety inspection teams.
Response within
24 hours
Free warranty
12 month
On-line training
Support
| Parameter | Specification |
|---|---|
| Model Number | KD2671A |
| Resistance Measurement Range | 0 - 1999.9 Ω |
| Measurement Accuracy | ±(1.5% + 1d) |
| Repeatability Error | ±0.5% Ω |
| Test Current | ≤100mA / ≥1A |
| Test Voltage | 12V |
| Power Supply | 6 x 1.5V (AA, R6) Batteries or Rechargeable |
| Power Consumption | < 150mA |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | < 85% RH (No condensation) |
| Storage Temperature | -10°C to 50°C |
| Dimensions (L*W*H) | 220mm × 200mm × 110mm |
| Weight | Approx. 1kg |
