Application Environment of KDZL-807 Automatic Interface Tension Tester
1. Applicable industry scenarios
Power industry: used for detecting interfacial tension of liquid media such as transformer oil and insulation oil, evaluating the degree of oil aging and purity, and ensuring the safe operation of power equipment.
Petrochemical industry: detecting surface/interfacial tension of crude oil, lubricating oil, fuel oil, additives, etc., used for oil quality control and formula development.
Pharmaceutical and Bioengineering: Measuring the interfacial properties of drugs, solvents, emulsions, etc. for drug stability, solubility, and formulation process optimization.
Food industry: used for surface tension analysis of liquids such as dairy products, edible oils, beverages, etc., to assist in food composition and quality control.
Universities and research institutions: as the core equipment for teaching and research experiments in physical chemistry, materials science, colloid chemistry, and other fields.
2. Physical environment requirements
Temperature: 10 ° C to 30 ° C (recommended for use in a constant temperature environment of 25 ° C to ensure measurement accuracy)
Humidity: Relative humidity<85% RH (without condensation)
Power supply: AC 220V ± 20%, 50Hz ± 10%, requires stable power supply, it is recommended to use anti surge socket
Installation location: Indoor, well ventilated, no strong electromagnetic interference, no corrosive gases, and no severe vibrations on the experimental table
Space requirement: The device size is 200 × 300 × 330 mm, and there should be reserved space for operation and heat dissipation (recommended tabletop size ≥ 500 × 500 mm)
3. Operation and usage conditions
Operator: Must have basic knowledge of chemistry or instrument operation, and can get started with simple training
Sample requirements: The liquid sample should be clear, free of particle impurities, and avoid contaminating the platinum ring
Calibration and maintenance: Regularly use standard solution (such as pure water) for single point calibration to maintain sensor sensitivity
Data Management: Supports local storage (255 timestamp records) and optional RS232 interface connection to computers, suitable for scenarios requiring data traceability or laboratory information management
