Compared with the previous generation of safety tester and other traditional instruments, with the principle of smaller, lighter, more stable and more in line with customer needs, the KDZD9661 series has completed a series of upgrades in terms of high density, small size, high performance, strong experience and long life, making the test easier.

1) Full function:
a) Integrated voltage resistance, insulation, grounding, leakage, power, start, LN loop detection eight functions;
b) One-time wiring, automatic test, easy operation;
c) Compliance with regulations: meet the national standard test requirements of industry and laboratory instruments;
2) Simple operation:
a) Clear display: 7 "touch screen and operation button dual system, clear test results, clear display
b) Eye-catching prompt: large font display of test voltage and current data, alarm light display, and eye-catching prompt;
c) Simple operation: built-in 100 groups of test programs, one wiring, one click start, automatic test, automatic data storage;
d) Scan test: scan start, automatic call test program, one-click test;
3) Complete protection:
a) Hardware protection: the product has under voltage, over voltage, over current, over temperature, over limit, power amplifier protection, overshoot protection, short circuit protection;
b) Software protection: over-limit protection, arc protection, open circuit detection, short circuit protection;
c) Operation safety: leakage protection, electric shock protection, open circuit protection, rapid discharge of residual voltage to ensure safe operation;
4) Informatization:
a) Rich interfaces: USB, RS232/485, LAN, I/O, PLC remote control interface, alarm light interface;
b) Data processing: can upload local server, network server, USB storage; Support MES system docking;
5) More efficient:
a) Safety test accuracy 1%, power test accuracy 0.2%;
b) Higher efficiency: a single test item can produce stable and accurate results in the shortest time of 1S;
c) Fast switching: only 20ms before switching between different test items, suitable for fast automated production lines;
d) Parallel test: grounding + voltage resistance/insulation test simultaneously, saving one test time;
6) Test function:
a) Electrical voltage: output capacity 500VA (ACW: 5KV/100mA; DCW 6KV/20mA,);
b) Insulation test: test voltage 2500V, test range up to 50GΩ;
c) Leakage test: support effective value, peak value, AC component, DC component, a variety of measurement modes;
d) Ground impedance: 40A/600mΩ, meet the medical device industry R<100mΩ test requirements;
e) Power test: Support 1.000W-12.000kW power measurement range;
f) Multiple support: LN loop test, open circuit detection function, quick start test, arc test;
