KD-212 Coiled Cable Multi-parameter Tester
KD-212 Coiled Cable Multi-parameter Tester

KD-212 Coiled Cable Multi-parameter Tester

Applications:

This tester is used for rapid batch testing of drum‑packaged shielded cables with cross‑sectional area 4–2500mm². It measures DC resistance and approximate length efficiently, providing reliable inspection for cable production, warehousing, and incoming quality control.

  • Response within
    24 hours

  • Free warranty
    12 month

  • On-line training
    Support

Profile:

The KD-212 integrates image recognition and multi‑electrical measurement. It accurately tests resistance, length, and temperature, supports temperature correction, and features high precision, strong anti-interference, and portable design for indoor and outdoor use.

Features:

  1. Supports rapid large‑scale testing of shielded drum cables with 4–2500mm² conductors.
  2. Consists of main unit and test clamps with resistance, length, temperature, and CPU modules.
  3. High-voltage sampling directly into A/D converter ensures higher measurement accuracy.
  4. Built-in overcurrent, overvoltage, and short‑circuit protection with excellent EMC performance.
  5. Portable structure for easy movement and convenient indoor and outdoor operation.

Parameter:

  1. DC resistance measurement range of cables: 0.1mΩ ~ 20kΩ
  2. Basic accuracy: 0.2%±2 digits With temperature correction function
  3. Cable length measurement range: 20m ~ 4000m
  4. Basic accuracy: ±3%±2 digits
  5. Temperature measurement range: -30~80℃
  6. Basic accuracy: ≤±0.5℃
  7. Display mode: large-screen LCD Chinese character display
  8. Communication interface: standard RS232 communication interface
  9. Dimensions:  370mm 430mm×350mm×370mm
  10. weight: 12kg
