Dielectric loss and dielectric constant is an important physical property of various metal oxides, plates, porcelain (pottery), mica, glass, plastics and other substances.

The factors affecting the dielectric loss and dielectric constant can be further understood through the measurement, which provides a basis for improving the properties of materials.

The instrument is used in research institutions, schools, factories and other units for the application of inorganic metal properties of new materials.

Scope of application:
Measurement of dielectric constant and dielectric loss coefficient of insulating material (loss Angle tangent value)

1. Q value measurement
a. Q value Measurement range: 5~999
b. Q value range: 30, 100, 300, 999, automatic shift
c. Nominal error
Frequency range: 10kHz~10MHz;
Inherent error: ≤5%± 2% of the full degree value; Working error: ≤7%± 2% of the full degree value;
Frequency range: 10MHz to 52MHz
Inherent error: ≤7%± 2% of the full degree value; Operating error: 107%± 2% of the full degree value.
2, capacitance measurement
a. Measuring range: 1~460pF(capacitance measurement above 460pF see the rules of use);
b. Capacity adjustment range
Main capacitor: 40~500pF;
Accuracy: ±1.5pF below 150pF; ±1% above 150pF;
Fine tuning capacity: -3pF~0~+3pF;
Accuracy: ±0.2pF.
3. Oscillation frequency
a. Oscillation frequency range: 10kHz~100MHz;
b. Frequency classification:
10~99 kHz 100~999 kHz
1.0 to 9.99 MHz 10 to 52MHz.
c. Frequency error: 2×10-4±1 word
4, Q qualified indicator preset function, preset range: 5~999.
5. Normal working conditions of the instrument
a. Ambient temperature: 0℃~+40℃;
b. Relative humidity: <80%;
c. Power supply: 220V±22V, 50Hz±2.5Hz
6. Sample size
Disc shape: thickness 2±0.5mm, diameter Φ30~40mm (ε<12), Φ25~35mm (ε=12~30), Φ15~20mm (ε>30)
7. Others
a. Power consumption: about 25W;
b. Net weight: approx. 7㎏;
c. Dimensions: (l×b×h) mm: 380×132×280.
