Profile:
Using fuzzy PID temperature control technology, the temperature control is accurate, the accuracy can reach ±0.02℃. Can be set 20℃, 40℃, 60℃, 80℃, 100℃ and other national standard temperature control points, and can be set a variety of temperature control
Features:
Using high definition color touch screen technology, the interface content is rich and clear, touch screen response is fast and flexible;
Using a large-capacity memory chip, up to 2000 measurement results can be stored;
The panel mounted thermal printer is used to automatically and quickly print the test result, sample number, test time, viscometer constant, pipe diameter, kinematic viscosity value and other information after the test.
Parameter:
Display: color LCD display + touch screen
Temperature control range: room temperature ~150℃
Set temperature: 20℃, 40℃, 50℃, 80℃, 100℃, other values (above room temperature ~150℃)
Temperature control accuracy: Number of test holes: 4 holes
Timing range: 0~999 seconds (according to the national standard, the flow time of each test sample must be higher than 200 seconds)
Timing accuracy: 0.1 seconds
Timing times: 1 to 4 times Optional
Storage capacity: 2000 test records
Printing method: Panel mounted thermal printer
Power supply: AC220V±5% 50Hz±5%
Power rate: 1600W
Operating temperature: 5℃~35℃
Ambient humidity: 10%~80%
